STANDARD FEATURES
- 16′ and 20′ lengths
- 102″ width
- 36″ non-removable 12GA steel sides
- 356 cu. ft. capacity on 16′ length
- 447 cu. ft. capacity on 20′ length
- 10″ x 30″ metering gate in solid rear gate
- standard on 24″ centers
- 3″ x 4.1 structural channel crossmembers on 24″ centers
- 8″ I-beam 18lbs. per ft
- 10″ channel iron with 3/16″ formed neck gusset
- 2″ x 8″ tongue and groove treated lumber floor
- self contained hydraulic 12V power unit
- electric brakes (all axles)
- 40º tilt “dump” angle
- adjustable 2-5/16 (25K) ball coupler (hitch)
- 1 spring loaded drop leg jack
- 8 hole 16″ wheels
- 235 85R 16 tires
- spare tire, wheel and rack
- mud flaps (dual wheels)
- safety chains
- lights meet U.S.DOT required specifications
- conspicuity (reflective) tape
- sandblasted, primed with rust inhibitive primer and painted with 2 coats of paint
- 5 year limited warranty
OPTIONAL FEATURES
- Axle Options #1 – 2- 8K axles 235 85R 16 radial tires
- Axle Options #2 – 2- 10K G.D. axles 2350 85R 16 radial tires
- Rear Gate Option #1 – 2 split swing out tailgates with 12″x15″ metering gates
- Rear Gate Option #2 – 2 split swing out tailgates without metering gates
- Rear Gate Option #3 – full dump tailgate with 12″x15″ metering gates
- Rear Gate Option #4 – full dump tailgate without metering gates
- 12″ and 24″ expanded metal extensions
- steel floor
- straight air / ABS brakes
- electric over hydraulics brakes
- 8′ portable steel ramps
- removable sides
- removable tie down bows for optional tarp
- 2 single speed jacks
- drop leg jacks with 2 speed gear box
- trailer without sides
